1983-2012 Mitsubishi 6 A Series Galant Service Repair Workshop Manual PDF

This is the COMPLETE Service and Repair Manual for the 1983-2012 Mitsubishi 6 A Series Galant Service Repair Workshop Manual PDF. It covers every single detail.

Mitsubishi Galant 1983-2012 Workshop Repair & Service Manual Complete digital official shop manual contains service, maintenance, and troubleshooting information for the Mitsubishi Galant 1983-2012. Diagnostic and repair procedures are covered in great detail to repair, maintain, rebuild, refurbish or restore your vehicle like a professional mechanic in local service/repair workshop. This cost-effective quality manual is 100% complete and intact as should be without any missing pages. It is the same factory shop manual used by dealers that guaranteed to be fully functional to save your precious time. This manual for Mitsubishi Galant 1983-2012 is divided into different sections. Each section covers a specific component or system and, in addition to the standard service procedures, includes disassembling, inspecting, and assembling instructions. A table of contents is placed at the beginning of each section. Pages are easily found by category, and each page is expandable for great detail. It is in the cross-platform PDF document format so that it works like a charm on all kinds of devices. You do not need to be skilled with a computer to use the manual. EXCERPT: AUTOMATIC TRANSAXLE OVERHAUL GENERAL DESCRIPTION This automatic transaxle is made up of the following main parts. The torque converter employs a 3 element, 1 step, 2 phase lock-up clutch. The gear train is made up of 3 multi-plate clutches, 2 multi-plate brakes and 2 planetary gears made up of a sun gear, carrier, pinion gear and annulus gear. The cases consist of a converter housing, transaxle case, rear cover and a valve body cover. Parts related to oil pressure regulation are the oil pump, which pressurizes the oil; the regulator, which controls the pressure setting; the solenoid valves, which change the oil pressure with electrical signals; the pressure control valve, which controls the oil pressure coming from the solenoid valve that effects each clutch and brake; each kind of valve, which carry out the retention of the oil pressure through the lines; and finally the valve body, which houses all the valves. SECTIONAL VIEW HYDRAULIC CIRCUIT 1. REVERSE CLUTCH 2. LOW-REVERSE BRAKE 3. SECOND BRAKE 4. UNDERDRIVE CLUTCH 5. OVERDRIVE CLUTCH 6. LOW-REVERSE ACCUMULATOR 7. SECOND ACCUMULATOR 8. UNDERDRIVE ACCUMULATOR 9. OVERDRIVE ACCUMULATOR 10. TORQUE CONVERTER CLUTCH 11. FAIL-SAFE VALVE A 12. FAIL-SAFE VALVE B 13. TORQUE CONVERTER CLUTCH CONTROL VALVE 14. COOLER 15. SWITCHING VALVE 16. LOW-REVERSE PRESSURE CONTROL VALVE 17. SECOND PRESSURE CONTROL VALVE 18. UNDERDRIVE PRESSURE CONTROL VALVE 19. OVERDRIVE PRESSURE CONTROL VALVE 20. TORQUE CONVERTER CLUTCH CONTROL SOLENOID VALVE 21. LOW-REVERSE SOLENOID VALVE 22. SECOND SOLENOID VALVE 23. UNDERDRIVE SOLENOID VALVE 24. OVERDRIVE SOLENOID VALVE 25. TORQUE CONVERTER PRESSURE CONTROL VALVE 26. REGULATOR VALVE 27. MANUAL VALVE 28. OIL FILTER 29. OIL PAN 30. OIL PUMP 31. RELIEF VALVE 32. OIL STRAINER ...

Instant download — no shipping, no waiting. Access it right away and use it as many times as you need.
