2000-2005 Mitsubishi Eclipse Spyder Service Repair Workshop Manual PDF
2000-2005 Mitsubishi Eclipse Spyder Service Repair Workshop Manual PDF
- Brand
- Mitsubishi
- Equipment
- Cars
- Models covered
- Eclipse
- Years
- 2000
- Format
- PDF, searchable, print-ready
- Delivery
- Instant download after checkout
- Language
- English
Couldn't load pickup availability
What happens after you pay
- Download link opens on the order page immediately
- The same link is emailed to you — re-download any time
- Open on phone, tablet or PC; print only the pages you need
- Not sure it covers your serial range? Ask us before you buy
This is the COMPLETE Service and Repair Manual for the 2000-2005 Mitsubishi Eclipse Spyder Service Repair Workshop Manual PDF. It covers every single detail.
2000-2005 Mitsubishi Eclipse Spyder Service Repair Manual VEHICLE/EQUIPMENT INTRODUCTION: The third-generation Mitsubishi Eclipse Spyder, produced from 2000 through 2005, represented a bold evolution in the affordable sports convertible segment. Built on Mitsubishi Motors refined GST platform, the Spyder combined the Eclipse s sharp coupe styling with an electronically actuated folding soft top, making it one of the most distinctive Japanese convertibles of the era. Under the hood, buyers could choose between the economical 2.4-liter 4G64 inline-four in the GS Spyder or the turbocharged 3.0-liter 6G72 V6 found in the GT Spyder, the latter producing around 210 horsepower. This generation featured independent MacPherson strut front suspension with a multi-link rear setup, delivering balanced handling for a convertible. Mitsubishi included advanced features for the time, including an available Rockford Fosgate premium audio system that doubled as a subwoofer, ABS brakes, and dual-stage front airbags. The Eclipse Spyder shared its powertrain technology with the Eclipse coupe and the Chrysler Sebring through the Diamond-Star Motors heritage, ensuring parts availability and established repair knowledge across multiple service networks. SERVICE & REPAIR SCOPE: - Engine service for 4G64 2.4L SOHC and 6G72 3.0L DOHC turbocharged engines - Manual transmission overhaul and automatic transmission rebuild procedures - Clutch system inspection, hydraulic release cylinder service - Brake system service including ABS module diagnosis and component replacement - Power convertible top motor, cables, and mechanism repair - Steering system service including power steering rack replacement - Suspension component replacement with alignment specifications - Air conditioning system evacuation, component replacement, and recharge procedures - Electrical system diagnosis with wiring circuit troubleshooting - Emission control system service including EGR, EVAP, and oxygen sensor testing - Cooling system flushing, thermostat replacement, and water pump service - Body panel removal and refit procedures for collision repair TECHNICAL SPECIFICATIONS: - Engine options: 2.4L 4G64 SOHC I4 (~147 hp) and 3.0L 6G72 DOHC turbo V6 (~210 hp) - Transmissions: 5-speed manual F5M42, 4-speed automatic F4A42 - Front suspension: MacPherson strut with coil springs and stabilizer bar - Rear suspension: Multi-link independent with coil springs - Front brakes: Ventilated disc, Rear brakes: Solid disc - Power steering: Rack and pinion - Wheelbase: 100.8 inches - Overall length: 175.4 inches - Curb weight: approximately 3200 to 3400 lbs depending on trim DIAGNOSTIC INFORMATION: - OBD-II diagnostic trouble code reading with manufacturer-specific code interpretation - Engine compression test procedures with minimum specification values - Turbocharger boost pressure test and wastegate actuator verification - Fuel pressure test with specification for both engine variants - Ignition system spark testin
Instant download — no shipping, no waiting. Access it right away and use it as many times as you need.
Delivery & file format
Delivery & file format
This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.
Check the serial range before you buy
Check the serial range before you buy
Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
