Takeuchi TB 15/120 Compact Excavator Parts Catalog

Takeuchi TB 15/120 Compact Excavator Parts Catalog

$16.99
$16.99
Sale Sold out
Shipping calculated at checkout.
Machine data plateRef 395751
Brand
Takeuchi
Equipment
Construction
Models covered
Takeuchi TB 15
Format
PDF, searchable, print-ready
Delivery
Instant download after checkout
Language
English

What happens after you pay

  • Download link opens on the order page immediately
  • The same link is emailed to you โ€” re-download any time
  • Open on phone, tablet or PC; print only the pages you need
  • Not sure it covers your serial range? Ask us before you buy
๐Ÿท๏ธ Basic Information
Identification
Make:
Takeuchi
Model:
TB15/120 Compact Excavator
Model Variant:
TB015
Production Years Covered:
Serial number 00543 and after
๐Ÿ‘‹ Introduction
Market Position
Target Audience:
Technicians and DIY owners of the Takeuchi TB015 compact excavator
Competitive Analysis
Advantage:
The TB015 is known for its compact size and maneuverability in tight spaces, making it suitable for residential and small-scale construction projects.
Key Features
Engine:
Powered by a Yanmar 3-cylinder diesel engine
Drive System:
Hydrostatic transmission with tracked undercarriage
Operating Weight:
Approximately 1500 kg
๐Ÿ“‹ Manual Details
Coverage
Covered Sections:
Lower Machinery, Upper Machinery 1-4, Hoe Attachment, Others, Hydraulic Device, Option, Engine Parts Catalog
Page Count:
N/A - not specified for this manual
Format
Manual Type:
Parts Catalog
Language:
English
Format:
PDF
Delivery Method:
Instant Download
๐Ÿ“– Manual Coverage
Systems Covered
Lower Machinery:
Undercarriage components including track, final drive, and frame
Upper Machinery 1:
Swing system, swing motor, and related components
Upper Machinery 2:
Hydraulic system components including pumps, valves, and lines
Upper Machinery 3:
Control system and electrical components
Upper Machinery 4:
Cab and operator controls
Hoe Attachment:
Excavator arm, boom, bucket, and linkage
Others:
Additional components not covered in other sections
Hydraulic Device:
Detailed breakdown of hydraulic components
Option:
Optional equipment and accessories
Engine Parts Catalog:
Engine assembly and parts breakdown
Procedures
Disassembly:
Step-by-step disassembly instructions for parts replacement
Assembly:
Step-by-step assembly instructions
Parts Identification:
Illustrated diagrams to help identify parts and part numbers
Technical Depth
Level of Detail:
Comprehensive parts catalog with exploded views and part numbers
Parts Information
Part Numbers:
Genuine Takeuchi parts numbers listed for each component
๐Ÿ“Š Manual Specifications
File Format
File Type:
PDF
Compatibility:
All versions of Windows and Mac
Requirements:
Adobe PDF Reader
Searchability:
The PDF is searchable, allowing quick reference of part numbers.
Print
Print Quality:
High resolution, suitable for printing.
Binding Type:
Digital download - no physical binding
Paper Type:
N/A - digital file
โš™๏ธ Engine Specifications
Primary Engine
Engine Model:
3TNA72L-UTBZ
Engine Manufacturer:
Yanmar
Engine Type:
Diesel
Number of Cylinders:
3
Performance
Power Output:
N/A - not specified for this model
Fuel System
Injection Type:
N/A - not specified for this model
๐Ÿ”ง Transmission
Standard Transmission
Transmission Type:
Hydrostatic
Drive System:
Tracked
Optional Transmission
N/A:
No optional transmission available for this model
Features
Automatic Shifting:
Not applicable (hydrostatic transmission)
๐Ÿ“ Dimensions
Exterior
Length:
N/A - not specified for this model
Width:
N/A - not specified for this model
Height:
N/A - not specified for this model
Weights
Curb Weight:
Operating weight approximately 1500 kg
๐Ÿ›ก๏ธ Safety Features
Crash Test Information
Crash Test Results:
N/A - construction equipment not subject to automotive crash tests
Active Features
ROPS:
Rollover protective structure - typically standard
FOPS:
Falling object protective structure - typically standard
Passive Features
Seatbelt:
Standard operator seatbelt
๐Ÿ’ก Technology Features
Infotainment
Audio System:
Not applicable - construction equipment
Driver Assistance
Telematics:
Not offered for this model
๐Ÿ”ง Maintenance
Service Intervals
Engine Oil Change:
Every 500 hours or annually, whichever comes first
Hydraulic Oil Change:
Every 1000 hours or as indicated in the machine manual
Fluid Specifications
Engine Oil Type:
API CD or higher, SAE 10W-30 or 15W-40 depending on ambient temperature
Hydraulic Oil Type:
Recommended hydraulic oil per Takeuchi specifications
Common Issues
Known Wear Items:
Track tension components, bucket pins, hydraulic hoses
๐Ÿ“š Vehicle History
Brand Heritage
Manufacturer:
Takeuchi Manufacturing Company, founded in 1963
Model Evolution
Series:
TB015 is part of Takeuchi's small excavator lineup
Production Location
Manufacturing Plant:
N/A - not specified for this model
๐Ÿ† Awards & Recognition
Recognition
Industry Recognition:
N/A - no specific awards found for this model

Delivery & file format

This is a digital PDF download, not a printed book. After payment the download link appears on your order confirmation page and is emailed to the address you entered. Files open in any PDF reader on phone, tablet or computer and can be printed.

Check the serial range before you buy

Manufacturers change procedures and part numbers by serial-number break. If your data plate shows a serial prefix that is not listed above, contact us with the model and serial number and we will confirm coverage before you order.
